Frame | M5 Alloy chassis and rear-end, Trail Geometry, SWAT™ Door integration, head tube angle adjustment, threaded BB, internal cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, 145mm of travel |
Fork | FOX FLOAT 38 Factory, GRIP X2 damper, HS and LS rebound and compression adjustment, 15x110mm QR axle, 44mm offset, 160mm of travel |
Crankset | Shimano SLX, M7120, 32T ring, 55mm chainline, S2-S3:165mm, S4-S6: 170mm |
Chain | Shimano SLX, M7100, 12-speed |
Cassette | Shimano SLX, CS-M7100, 12-speed, 10-51t |
Shift Levers | Shimano SLX, M7100, 12spd |
Rear Derailleur | Shimano SLX, M7100, SGS, 12-speed |
Front Brake | TRP DH-R EVO, 4-piston caliper, hydraulic disc, 220mm |
Rear Brake | TRP DH-R EVO, 4-piston caliper, hydraulic disc, 203mm |
Rims | Roval Traverse, hookless alloy, 30mm inner width, tubeless ready, Front: 29, Rear: 27.5 |
Front Tyre | Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3 |
Rear Tyre | Eliminator, GRID GRAVITY casing, GRIPTON® T9/T7 compound, 2Bliss Ready, 27.5x2.3 |
Handlebars | Deity, Racepoint, 5-degree upsweep, 9-degree backsweep, 810 width, S2: 25mm rise: S3-S6: 38mm rise |
Grips | Deity, Knuckleduster, Black |
Saddle | Bridge Comp, Hollow Cr-mo rails, S1-S2: 155mm, S3-S6: 143mm |
Seat Post | PNW Loam OE Dropper, tool-less travel adjust, Range lever, 34.9, S2: 150mm, S3: 170mm, S4-S6: 200mm |
Seat Binder | Alloy, 38.6mm |
Inner Tubes | Standard, Presta valve |
Bottom Bracket | Shimano, BB-MT801, Threaded |
Front Hub | DT Swiss 370, 15x110mm, 28h |
Rear Hub | DT Swiss 370, 12x148mm, 32h |
Spokes | Sapim Force |
Stem | Deity, 35mm clamp, 35mm length |
Swat | SWAT internal downtube storage |
Please note: Manufacturers can sometimes change the specification of the products from time to time.
