2020 Orange Five Pro

Orange

Price £4,100.00

New Radically revised progressive suspension frame curve

New re-worked geometry for confidence, speed and stability

New Geometry optimised for 150mm front/145mm rear travel

Custom options

It’s difficult to create an introduction for a bike with the reputation of the Five. It’s the original utility high-performance bike. In 20 years, its basic silhouette hasn’t really changed; you’d never mistake it for another bike. It’s the bike you ride at your local ‘spot’ on the weekend with your mates, it’s the bike you get out for a quick evenings lap, it’s the bike you ride all through winter – day or night, the bike you race enduro on, you do your first downhill race on, and the one you can take on your annual trip to the Alps. It’s the quiver killer, and it’s still a Five.

The Five still rolls on 27.5 inch wheels, albeit with meatier tyres than last year, maintains its 150mm travel fork but gains additional travel at the rear which now sits at 145mm. It has adopted the use of a metric shock and the frame has been tuned to be more progressive offering more support and bottom out resistance whilst we’ve also improved small bump compliance in the initial part of the stroke. We’ve also slightly reduced the bikes anti-squat numbers, but it still has that great turn of pace and dynamic delivery you’d expect when you get on the pedals.

A huge part of what gives our bikes their character is their geometry and the five is no different with a whole host of changes. The head angle has now slackened a degree to 65, while the BB is 5mm lower, chain stays have increased by 7mm, and the reach has increased by 10mm (size L). While the head tubes on the large and X-large bikes have been shortened as a result of rider feedback.

Much like its stable mate the Alpine 6 we have made sizing revisions to the Five giving people a better range to choose from. The XS has been dropped from the range while we’ve added a XXL at the other end of the scale and shortened the seat tube on the XL.

We’ve worked on the smaller details as well, our cable routing has seen an overhaul to be easier on the eye and keep those big loops to a minimum. All the CNC parts on the frame, upper and lower shock mounts, dropouts and bearing housings have all seen revisions.

So whatever you have planned for your Five it’ll be better prepared than ever to take you there and back with the most amount of fun and least amount of fuss.

The bikes silhouette is iconic and so is its ride.

Orange Five Highlights

  • Frame designed and built in Britain
  • 5 year frame warranty
  • Single pivot suspension for the utmost performance, efficiency and reliability
  • New Radically revised progressive suspension frame curve
  • New re-worked geometry for confidence, speed and stability
  • New Geometry optimised for 150mm front/145mm rear travel
  • New Frame bottle bosses
  • 27.5 inch wheels
  • Boost 148 rear hub spacing
  • Aggressive trail geometry
  • Long top tube and wheelbase for high-speed stability
  • Internal dropper post routing​
  • Choose from 10 custom colours
  • Fine tune the Five with custom upgrade options
Show more

Customise your ride

FRAME & FORK

Frame 6061-T6 Monocoque UK Formed Custom Aluminium Tubing.

Wheel Size: 27.5

Rear wheel travel: 145mm

Fork Fox Performance 34 Float 150mm 27.5

Rear Shock Fox Float DPS Performance 210x55

Headset Cane Creek 49mm For Tapered Steerer

Rear Axle Bolt Type Allen Key Head (Boost 148 Hub)

WHEELS & TYRES

Wheelset WTB ST Light i30 on Strange Pro 27

Tyres Maxxis DHR II 2.4 Exo TR 27.5

DRIVETRAIN

Crankset SRAM Descendant 6K DUB

Rear Mech SRAM GX Eagle 12spd

Cassette SRAM NX Eagle 1230 11-50T

Shifters SRAM NX Eagle 12spd

Bottom Bracket SRAM DUB

Chain SRAM NX Eagle

BRAKING

Brakes SRAM Guide RE 200/180

FINISHING KIT

Stem Race Face Chester M35 x 40mm

Handlebar Burgtec RideWide Enduro 800mm

Grips Strange 130 Single Lock-On Black

Seatpost SDG Tellis 150mm

Saddle WTB Silverado Sport

Seat Clamp Strange Bolted Black
